MONOLITH S

Wheel data entry:
Automatic input of diameter
Manual input of distance
Automatic input of distance

Type of screen:
LCD monitor

Type of monitor:
Touchscreen

Shaft diameter:
Ø 40 mm

Type of clamping:
Manual locking HAWEKA

Laser on Top (12):
Opcja dodatkowa do zamontowania

Index

MONOLITH S

availability

Available

net price

gross price

Delivery price

150zł netto

The balancer is equipped with a patented system of automatic wheel parameters input based on real camera image. The laser pointer defines more precisely the correction point and shows the exact position for adhesive weights application.





Standard equipment:

  • Automatic protection hood
  • Automatic electric-brake at unbalance position
  • Calibration
  • Voice synthesizer
  • Laser adjuster
  • Alu programmes
  • Automatic positioning lock
  • Contactless wheel parameters measurement
  • Optimization
  • USG rim width measurement
  • Programme 3P  – “hidden weight”
  • Touchscreen LED monitor
  • Print to file
  • Operator’s memory
  • Automatic diameter, width and offset measurement
  • Unbalance recalculating
  • Manual clamp Haweka Progrip with 3 cone

Distinctive features:





Rim diameter range:

10” – 30”

Rim width range:

2” – 15”

Maximum wheel weight

80 kg

Balancing accuracy

1 g

Imbalance position indicator accuracy

0.45°

Measuring speed

140 obr/min

Power of the drive engine

80 W

Electric supply

230V / 50 Hz

Pneumatic power supply

8 - 10 bar

Dimensions

980/1250/1490

Weight

120 kg
