TRENTA

Max. Clamp capacity:
up to 30 inches

Max. wheel diameter:
1600 mm

Max. wheel width:
780 mm

Max. wheel weight:
1500 kg

Index

TRENTA 30

availability

Available

net price

gross price

Delivery price

For very wide tyres for trucks, agricultural and construction machines on steel and aluminum rims. The self-centering wheel holder is operated by a high-pressure hydraulic system. The pressure gauge indicates the working pressure. The maximum working pressure is 130 bar but for weaker or particularly thin rims it is recommended to limit this pressure. Two-speed spindle is an additional advantage.

Clamping capacity

17" - 30"

Max. wheel width

780 mm

Max. wheel diameter

1600 mm

Bead-breaker pressure force

1865 kg

Maximum wheel weight

1500 kg

Pneumatic supply

130 bar

Table rotation speed

6 / 12 obr./min.

Electric supply

3 x 400V / 50 Hz

Motor power

1,1 kW / 1,5 kW

Pump motor

1,3 kW / 1,8 kW

Weight

650 kg

Wheel clamp

Hydrauliczny

Dimensions

1600/1050/1600
